Note by Blyss Sarania: Scarlet.Crush hasn't logged on to the forum in 5 months, and there hasn't been an update to this project in a while. The wrapper works well enough as is, but there has been an unofficial continuation of the project here. Note that Scarlet.Crush is not involved in that, it's just a continuation of the project based on his source. You can either use Scarlet.Crush's version which is found here in this post, or you can use the updated version in the thread previously linked. Choose whatever suits your needs best. End note.
Updated : New version released 1.2.0.160. See post #2505.
Updated : Update Available 1.2.1.165 - WinXP compatibility for ScpUser.exe/XInput1_3.dll, Service Channel Bypass feature added, Proof of Concept KBM mapping sample added. See Post #2574.
Updated : Update Available 1.2.2.175 - Includes all previous Updates. Added Fixup for 00:26:5C signature, Renamed ScpPad2Key -> GtaMapper, added DskMapper & D3Mapper samples. Refactored & moved common functionality into ScpControl.dll. See Post #2702.
Download latest version here. [1.2.0.160]
Download latest update here. [1.2.2.175]
Download latest source here. [1.2.2.175]
Requirements
1. Microsoft .NET 4.0
2. Visual C 2013 Runtime.
3. Latest DirectX Runtime.
4. Latest Xbox 360 Controller Drivers available.
5. Genuine Sony DualShock3 or DualShock4 or SixAxis Controller(s).
6. Minimum of Bluetooth 2.0 + EDR Dongle (if using Bluetooth).
7. Administrator rights on your PC.
Note : The Bluetooth Driver requires that you dedicate a Bluetooth Dongle to DS3/DS4 use. It will not be usable by other Bluetooth devices after the driver has been installed.
Important - make sure your Bluetooth dongle and DS3(s) are plugged in via USB before installing the drivers.
Xbox 360 Controller Drivers - these are available from Microsoft here.
Windows 7 - Run before installing the SCP Drivers. (Windows 7 shipped with outdated drivers which may cause stability issues)
Windows XP and Vista - Run after after installing the SCP Drivers.
Windows 8/8.1 not required.
New Install
1. Connect your Dongle and DS3 via USB and let Windows install it's default drivers.
2. Copy the archive to a temporary directory [eg C:Temp].
3. Right click on the archive and select Properties.
4. Click the Unblock button if it is displayed on the General tab.
5. Unpack the archive.
6. Create a directory where you want the Service to run from. [Recommended - C:Program FilesScarlet.Crush Productions *]
7. Copy the contents of the ScpServerbin to the directory you created.
8. Run ScpDriver.exe.
9. XP/Vista - check the Force Install option. Win 7/8 leave it unchecked.
10. Click Install. [see screenshot below]
11. If you do not see the install summary as per screenshot and your dongle is in the directly supported list - click Uninstall, check the Force Install option, click Install.
12. Click Exit.
* create from an elevated command prompt if you have UAC enabled. The directory should not be created anywhere off your User directory (eg on your Desktop, or in your Downloads directory), it should also not be on a Network drive.
Upgrade from 1.1.0.139
1. Copy the archive to a temporary directory [eg C:Temp].
2. Right click on the archive and select Properties.
3. Click the Unblock button if it is displayed on the General tab.
4. Unpack the archive.
5. Stop the Service [net stop 'SCP DS3 Service' - from an elevated command prompt, or use Service Control Manager]
6. Close ScpMonitor if it is running. [Right-click on the icon in the Task bar and select Exit]
7. Copy the contents of the ScpServerbin folder to your existing install folder. **
8. Start the Service [net Start 'SCP DS3 Service' - from an elevated command prompt, or use Service Control Manager]
** The DS3, BTH and Bus drivers have not changed, so you do not need to re-run ScpDriver.exe.
Apply Update
1. Copy the archive to a temporary directory [eg C:Temp].
2. Right click on the archive and select Properties.
3. Click the Unblock button if it is displayed on the General tab.
4. Unpack the archive.
5. Stop the Service [net stop 'SCP DS3 Service' - from an elevated command prompt, or use Service Control Manager]
6. Close ScpMonitor if it is running. [Right-click on the icon in the Task bar and select Exit]
7. Copy the contents of the ScpServerbin folder to your existing install folder.
8. Start the Service [net Start 'SCP DS3 Service' - from an elevated command prompt, or use Service Control Manager]
Driver installation for DualShock 4 - See Post #1852.
Pairing a DS4 to your Bluetooth Dongle - plug in the DS4 to USB while the Service is running, the DS4 will be automatically paired if required.
Pairing a DS3 to your Bluetooth Dongle - plug in the DS3 to USB while the Service is running, the DS3 will be automatically paired if required.
Disconnecting a DS3 - Press and hold L1 + R1 + PS for 2 seconds.
The drivers support 4 DS3s connected by USB or via Bluetooth (one dongle can support 4 DS3 connections).
Supported OS - XP (x86), Vista (x86, amd64), Win 7 (x86, amd64), Win 8 (x86, amd64), Win 8.1 (x86, amd64)
See Post #1851 if your dongle is not on the list below.
Directly Supported Dongles
USBVID_03F0&PID_231D
USBVID_045E&PID_3500
USBVID_0461&PID_4D75
USBVID_046D&PID_C709
USBVID_047D&PID_105E
USBVID_0489&PID_E011
USBVID_0489&PID_E042
USBVID_0489&PID_E04E
USBVID_04CA&PID_3006
USBVID_050D&PID_016A
USBVID_05AC&PID_821A
USBVID_05AC&PID_821F
USBVID_07D1&PID_F101
USBVID_0930&PID_0215
USBVID_0A12&PID_0001
USBVID_0A5C&PID_200A
USBVID_0A5C&PID_2101
USBVID_0A5C&PID_2146
USBVID_0A5C&PID_2148
USBVID_0A5C&PID_2150
USBVID_0A5C&PID_2153
USBVID_0A5C&PID_217D
USBVID_0A5C&PID_2198
USBVID_0A5C&PID_21E1
USBVID_0A5C&PID_21E8
USBVID_0B05&PID_1715
USBVID_0B05&PID_1783
USBVID_0B05&PID_1785
USBVID_0B05&PID_179C
USBVID_0B05&PID_17B5
USBVID_0B05&PID_B700
USBVID_0C10&PID_0000
USBVID_0CF3&PID_3002
USBVID_0CF3&PID_3004
USBVID_0CF3&PID_3005
USBVID_0DB0&PID_3801
USBVID_0DF6&PID_2200
USBVID_0E5E&PID_6622
USBVID_1131&PID_1001
USBVID_1131&PID_1004
USBVID_1286&PID_2044&MI_00
USBVID_13D3&PID_3304
USBVID_413C&PID_8126
USBVID_8086&PID_0189
USBVID_8087&PID_07DA
USBVID_0930&PID_0214
USBVID_0A5C&PID_2154
USBVID_0489&PID_E04D
USBVID_413C&PID_8197
USBVID_0A5C&PID_2021
USBVID_05AC&PID_8286
USBVID_0A5C&PID_2100
USBVID_0BDA&PID_8723
USBVID_044E&PID_3010
USBVID_0B05&PID_1788
USBVID_0A5C&PID_2190
USBVID_13D3&PID_3315
USBVID_0489&PID_E027
USBVID_05AC&PID_821D
USBVID_0BDA&PID_0724
USBVID_050D&PID_065A
USBVID_0A5C&PID_21E3
USBVID_05AC&PID_8216
USBVID_0A5C&PID_21B4
Tools
ScpServer.exe : GUI based version of the Service.
ScpPair.exe : GUI tool to allow pairing a DS3 with an external device (eg Nexus Tablet).
Zadig.exe : GUI tool (libwdi) which allows installing WinUSB on DS4s and Bluetooth dongles which do not appear on the supported list.
___________________________________________________________________
The Filter Driver + Wrapper is no longer supported.
An updated XInput Wrapper is included as part of the Driver Package and maintains backward compatibility with :
- DS3 on SCP Filter Driver
- DS3 on libusb-win32 Filter Driver
- DS2 on Play.com USB Adapter
- SpeedLink Strike FX pad.
___________________________________________________________________
